Parameters

2x2

2x16

Operating Wavelength(nm)

1260~1650

Fiber Type

G657A1

Insertion Loss (dB)(S/P Grade)

4.8/4.5

14.1/13.8

Loss Uniformity (dB)

0.5

1.2

Return Loss (dB) (S/P Grade)

50/55

50/55

Polarization Dependent Loss(PDL, dB)

0.2

0.3

Directivity (dB)

55

55

Wavelength Dependent Loss(dB)

0.3

0.5

Temperature Stability(-40~85 °C)(dB)

0.5

0.5

Operating Temperature (°C)

-40~85

Storage Temperature (°C)

-40~85
