MPO/MTP In-line Fiber Attenuator

Description

The MPO/MTP attenuator can achieve uniform attenuation of optical signal strength in each channel of 40/100G parallel optical transmission systems or other MPO interconnection devices. Compared with the traditional attenuation method that requires multiple independent attenuators to be applied separately to different optical signal channels, the network configuration design of this product is significantly simplified; at the same time, it can reduce the operational space and save installation time.
The signal conditioning module is specially designed for MPO/MTP links, precisely controlling the optical power with a fixed attenuation value (1-30DB + 0.5DB) to prevent overload damage to high-density optical modules. It is compatible with 12/24-core multimode OM4 and single-mode G.657A1 systems.

Parameter	Technical Specifications		Units
Fiber type	Single-Mode	Multi-Mode	/
Operation bandwidth	1310 / 1550	850 / 1300	nm
Attenuation values	1~20		dB
Fiber channel	12/24/48	16/32	Ch
Attenuation tolerance	+1dB (1~10dB)	±10% (11~20dB)	dB
Return loss	60dB (80° polish, SM)	/	dB
Working temperature	-20~+75		℃
