| Fiber count | Max. cores in tube | Cable diameter (mm) | Weight (kg/km) | ||
| 48~144 | 12×12 | 12.9~15.6 | 160~230 | ||
| 156~216 | 12×18 | 16.1~18.1 | 240~300 | ||
| 240~576 | 24×24 | 19.7~23.1 | 355~490 | ||
Tensile Strength （N） | Long term | Short term | |||
| 600 | 1500&0.8G (G-Cable weight) | ||||
| Crush Resistance | Long term | Short term | |||
| 300 | 1000 | ||||
| Bending Radius | Static | Dynamic | |||
| ≥10D | ≥20D | ||||
| Operating Temperature(℃) | -40℃ ~ +60℃ | ||||
