Description

The GYDTS optical cable is an outdoor communication optical cable. It adopts a loose-lay layer-wound light-armored structure, featuring excellent mechanical properties, temperature characteristics and waterproof capabilities. It is suitable for various laying methods such as in pipelines, on poles, and in the ground.

Features

High-Density Access and High Splicing Efficiency；
Excelled mechanical and environmental performance；

Applications

Adopted to Outdoor distribution;
Suitable for aerial; duct;
Long distance and local area network communication;

Specification


Fiber count

Element

number

MAT

  (N)

 Cable

diameter

 (mm)

Weight

(kg/km)

72~288     4 6×12   18.3
  330
300~360     5 6×12   19.9  380
372~432     6
 6×12   21.6  440
576     412×12   23.2  510

Tensile Strength

        （N）

     Long term      Short term
        600

     1500&0.8G

 (G-Cable weight)

Crush Resistance     Long term      Short term
         300          1000
Bending Radius        Static        Dynamic
        ≥10D          ≥20D
Operating
Temperature(℃)		            -40℃ ~ +60℃
