| Fiber count | Element number | MAT (N) | Cable diameter (mm) | Weight (kg/km) | |
| 72~288 | 4 | 6×12 | 17.7 | 285 | |
| 300~360 | 5 | 6×12 | 19.3 | 335 | |
| 372~432 | 6 | 6×12 | 21.0 | 390 | |
| 576 | 4 | 12×12 | 22.6 | 450 | |
Tensile Strength （N） | Long term | Short term | |||
| 600 | 1500&0.8G (G-Cable weight) | ||||
| Crush Resistance | Long term | Short term | |||
| 300 | 1000 | ||||
| Bending Radius | Static | Dynamic | |||
| ≥10D | ≥20D | ||||
| Operating Temperature(℃) | -40℃ ~ +60℃ | ||||
