Self-Support Cable Series

GYWFXTCBY
Contact Us

Description

The GYWFXTCBY cable is an optical cable structure specifically optimized for aerial installation in the access and drop segments of telecommunication networks. Its design adheres to the core principles of being "lightweight, high-density, cost-effective, and easy to deploy." Through innovative structural integration, it achieves an optimal balance between performance and economic efficiency for short-to-medium span aerial environments.

Features

Superior Mechanical and Environmental Performance;
High Economic Efficiency and Easy Deployment;
Flexible Design and High Reliability;

Applications

Self -Support Aerial;
FTTH (Fiber to the Home) Networks;
Wireless Mobile Networks (4G/5G);
Local Access Networks and Drop Cables;
Temporary Communication Setups or Emergency Restoration;

Specification

Fiber count

   Tube

 FRP

        Cable

diameter (mm)

Weight

(kg/km)

2~12    2.2
  2.1      8.0×4.5    40
14~24    3.0  2.3      9.0×5.0    50
Crush Resistance    Long term        Short term
        600            1200
Bending Radius       Static          Dynamic
      ≥10D            ≥20D
Operating
Temperature(℃)
            -40 ~ +60
