Self-Support Cable Series

Description

The GYFTYC8S optical cable is a figure-8 self-supporting outdoor communication cable specifically designed for aerial installation. It features a loose tube, stranded, filled core structure that integrates the fiber protection unit with a high-strength steel messenger wire in a distinctive figure-8 cross-section. This design allows the cable to be directly suspended between utility poles without requiring a separate support wire, significantly simplifying the installation process and greatly reducing the cost and time for deploying aerial lines.

Fiber count	Element number	MAT (N)	Cable diameter (mm)	Weight (kg/km)
2~30	5	7000	11.5	240
32~60	5	7000	12.2	255
Crush Resistance	Long term		Short term
	1000		3000
Bending Radius	Static		Dynamic
	≥10D		≥20D
Operating Temperature(℃)	-40℃ ~ +60℃
