| Fiber count | Element number | Max. cores in tube | Cable diameter (mm) | Weight (kg/km) | |
| 2~30 | 5 | 6 | 8.9 | 165 | |
| 32~36 | 6 | 6 | 9.3 | 170 | |
| 38~60 | 5 | 12 | 9.4 | 170 | |
| 62~72 | 6 | 12 | 9.9 | 180 | |
| 74~84 | 7 | 12 | 10.5 | 190 | |
| 86~96 | 8 | 12 | 11.1 | 200 | |
| 98~108 | 9 | 12 | 11.7 | 210 | |
| 110~120 | 10 | 12 | 12.3 | 225 | |
| 122~132 | 11 | 12 | 12.9 | 235 | |
| 134~144 | 12 | 12 | 13.5 | 250 | |
| Tensile strength | 1200N | ||||
| Crush Resistance | Long term | Short term | |||
| 300 | 1000 | ||||
| Bending Radius | Static | Dynamic | |||
| ≥10D | ≥20D | ||||
| Operating Temperature(℃) | -40℃ ~ +60℃ | ||||
