| Fiber count | Element number | MAT (N) | Cable diameter (mm) | Weight (kg/km) | |
| 2~30 | 5 | 6000 | 8.6 | 170 | |
| 32~36 | 6 | 6000 | 9.0 | 185 | |
| 38~60 | 5 | 6000 | 9.1 | 180 | |
| 62~72 | 6 | 6000 | 9.6 | 200 | |
| 74~84 | 7 | 7000 | 10.2 | 205 | |
| 86~96 | 8 | 7000 | 10.8 | 215 | |
| 98~108 | 9 | 7000 | 11.4 | 230 | |
| 110~120 | 10 | 8000 | 12.0 | 240 | |
| 122~132 | 11 | 8000 | 12.6 | 255 | |
| 134~144 | 12 | 8000 | 13.2 | 265 | |
| Crush Resistance | Long term | Short term | |||
| 300 | 1000 | ||||
| Bending Radius | Static | Dynamic | |||
| ≥10D | ≥20D | ||||
| Operating Temperature(℃) | -40℃ ~ +60℃ | ||||
