| Fiber count | Element number | Max. cores in tube | Cable diameter (mm) | Weight (kg/km) | |
| 2~36 | 6 | 6 | 12.7 | 165 | |
| 38~72 | 6 | 12 | 13.5 | 185 | |
| 74~84 | 7 | 12 | 14.1 | 200 | |
| 86~96 | 8 | 12 | 14.7 | 215 | |
| 98~108 | 9 | 12 | 15.3 | 230 | |
| 110~120 | 10 | 12 | 15.9 | 245 | |
| 122~132 | 11 | 12 | 16.7 | 265 | |
| 134~144 | 12 | 12 | 17.3 | 280 | |
| 146~216 | 6 | +12 | 12 | 18.8 | 340 |
| 218~240 | 7 | +13 | 12 | 19.6 | 365 |
| 242~264 | 8 | +14 | 12 | 20.2 | 385 |
| 266~288 | 8 | +15 | 12 | 21.0 | 415 |
Tensile strength | Long term | Short term | |||
| 1000 | 3000 | ||||
Crush Resistance | Long term | Short term | |||
| 1000 | 3000 | ||||
Bending Radius | Static | Dynamic | |||
| ≥12.5D | ≥25D | ||||
| Operating Temperature (℃) | -40℃ ~ +60℃ | ||||
