GYTY53
Contact Us

Description

The GYTY53 type optical cable is a high-performance communication optical cable, widely used in modern communication networks.  The product has completed mass production, with mature and stable production process, strict quality control requirements, regular product performance verification to ensure the reliability of the product. This product has good mechanical property and environmental performance.

Features

Steel wire strength. Filler protect tube fiber. Steel tape armor；
Good ultra violet radiation resistant property；
Double sheath .Good moisture-resistance；

Applications

Adopted to Outdoor distribution；
Suitable for aerial duct and buried method；
Long distance and local area network communication；

Specification


Fiber count

Element

number

Max.  cores

in tube

 Cable

diameter

 (mm)

Weight

(kg/km)

2~36     6       6
   11.8
    145
38~72     6      12   12.4
   160
74~84     7
      12   13.0   175
86~96     8      12   13.8   190
98~108     9      12   14.4   205
110~120    10      12   15.0   220
122~132    11      12   15.6   235
134~144    12      12   16.2   250
Tensile strength        Long term      Short term
             1000          3000
Crush Resistance        Long term      Short term
             1000          3000
Bending Radius           Static        Dynamic
           ≥10D          ≥20D
Operating
Temperature (℃)		            -40℃ ~ +60℃
