GYXTA/S
Contact Us

Description

The GYXTA/S optical fiber cable is a type of outdoor telecommunication cable designed with a central tube structure, offering excellent mechanical properties and environmental resistance. The GYXTA/S optical fiber cable is a type of outdoor telecommunication cable designed with a central tube structure, offering excellent mechanical properties and environmental resistance.

Features

Superior Protection;
Excellent Mechanical Properties;
Strong Environmental Adaptability;

Applications

Metropolitan Area Networks (MAN) & Access Networks;
Aerial Installation;
Duct Installation;
Direct Burial Installation;

Specification


Fiber count

Element

number

   Cable

diameter

   (mm)

Weight

(kg/km)

2~12     12   7.8
    85
14~24     24   8.6
   110
Tensile strengthLong term      Short term
     600         1500
Crush ResistanceLong term      Short term
     300         1000
Bending Radius    Static        Dynamic
   ≥10D          ≥20D
Operating
Temperature(℃)		            -40℃ ~ +60℃
