Duct / Aerial Cable Series

Description

GYXTY optical cable is a central tube type optical cable designed for outdoor communication scenarios. It features a metal reinforcing component as the tensile core, and the interior is fully filled to enhance water resistance. The outer layer is covered with a polyethylene sheath containing reinforcing elements.
The product has completed mass production, with mature and stable production process, strict quality control requirements, regular product performance verification to ensure the reliability of the product. This product has good mechanical property and environmental performance.

Features

Small outer diameter, light weight, convenient construction;

Stable control of optical fiber excess length;

After cable formation, the additional attenuation of the optical fiber is nearly zero, and the dispersion value remains unchanged;

Excellent mechanical and environmental performance;

Can be installed conveniently and operated simply;

Fiber count	Element number	Cable diameter (mm)	Weight (kg/km)
2~12	12	7.3	55
14~24	24	7.8	65
Tensile strength	Long term	Short term
	600	1500
Crush Resistance	Long term	Short term
	300	1000
Bending Radius	Static	Dynamic
	≥10D	≥20D
Operating Temperature(℃)	-40℃ ~ +60℃
