Duct / Aerial Cable Series

GYXTW
Contact Us

Description

GYXTW optical cable is a type of optical cable widely used in the field of communication.
The product has completed mass production, with mature and stable production process, strict quality control requirements, regular product performance verification to ensure the reliability of the product. This product has good mechanical property and environmental performance.

Features

Small outer diameter, light weight, convenient construction;
Stable control of optical fiber excess length;
After cable formation, the additional attenuation of the optical fiber is nearly zero, and the dispersion value remains unchanged;
Excellent mechanical and environmental performance;
Can be installed conveniently and operated simply;

Applications

Suitable for aerial .pipeline laying method;
Long distance and local area network communication;
Adopted to Outdoor distribution;

Specification


Fiber count

Element

number

 Cable

diameter

 (mm)

Weight

(kg/km)

2~12     12   7.3
    60
14~24     24   7.8
    70

Tensile strength
Long term      Short term
     600         1500

Crush Resistance
Long term      Short term
     300         1000

Bending Radius
    Static        Dynamic
   ≥10D          ≥20D
Operating
Temperature(℃)
            -40 ~ +60
