GYFTY
Contact Us

Description

GYFTY is mainly used in power systems where there is a high incidence of lightning and severe electromagnetic interference.
The product has completed mass production, with mature and stable production process, strict quality control requirements, regular product performance verification to ensure the reliability of the product. This product has good mechanical property and environmental performance.

Features

Non-metal strength member;
Filler protect loose tuber fiber;
Non-metal strength has an excellent anti-electromagnet ability；

Applications

In general, non-metallic optical cables are mainly used in large base stations or computer rooms, etc., to prevent lightning and electrical interference from entering the room.
Adapted to trunk power transmission system;
Adapted to Outdoor distribution;
Duct, Aerial

Specification


Fiber count

Element

number

Max. cores

in tube

 Cable

diameter

 (mm)

Weight

(kg/km)

2~4886
10.2
90
50~8471210.6
100
86~9681211.1110
98~1089
1211.4
115
110~120101212.0130
122~132111212.6
140
134~144121213.2
155

Tensile strength		         Long term     Short term
             600       1500&1G
 (G—Cable weight)

Crush Resistance		         Long term      Short term
             300           1000

Bending Radius		            Static        Dynamic
            ≥10D           ≥20D
Operating
Temperature(℃)		                          -40℃ ~ +60℃
