Duct / Aerial Cable Series

Description

GYTA/S is a common outdoor loose-laid armored optical cable used for transmitting communication signals. It belongs to the type of communication outdoor optical cables and is mainly suitable for pipe, overhead or underground laying environments. It uses a metal reinforcing core as the supporting structure, placing 250μm optical fibers inside a loose jacketed tube filled with waterproof compound, forming a compact core cable around the central twisted pair. The outer layer is longitudinally wrapped with plastic-coated aluminum tape and encapsulated with extruded polyethylene sheath to achieve tensile resistance, waterproofing and UV resistance properties.
The product has completed mass production, with mature and stable production process, strict quality control requirements, regular product performance verification to ensure the reliability of the product. This product has good mechanical property and environmental performance.

Specification

Fiber count	Element number	Max. cores in tube	Cable diameter (mm)	Weight (kg/km)
2~30	5	6	9.1	80
32~36	6	6	9.5	95
38~60	5	12	9.6	90
62~72	6	12	10.1	110
74~84	7	12	10.7	120
86~96	8	12	11.3	130
98~108	9	12	11.9	145
110~120	10	12	12.5	155
122~132	11	12	13.3	170
134~144	12	12	13.9	185
146~216	6+12	12	15.2	240
218~240	7+13	12	16.0	265
242~264	8+14	12	16.6	280
264~288	9+15	12	17.4	305
Tensile strength	Long term		Short term
Tensile strength	600		1500&1G (G—Cable weight)
Crush Resistance	Long term		Short term
Crush Resistance	300		1000
Bending Radius	Static		Dynamic
Bending Radius	≥10D		≥20D
Operating Temperature(℃)	-40℃ ~ +60℃
