HDMI Matrix 4×4 With Audio

ADH44
HDMI Matrix 4x4 With Audio (4K@30Hz)
Contact Us

Description

The HDMI matrix 4×4 can connect 4 HD signal sources to 4 HD display terminals with optical fiber and stereo headphone output at the same time via HDMI out 1 port.
The matrix allows four HDMI devices to be switched or split easily to four HDMI compatible monitors or projectors.

Features

Support HDCP 1.4;
Very compact structure;
Stable and reliable;
Via HDMI out 1, support 3.5mm earphone jack and optical output at same time;
Economical and cost-effective;
Support 3D;
Support IR Remote Control;
Support RS232 Control;
The four outputs could show the same or different source simultaneously;

Applications

This HDMI matrix support lossless transmitting and are widely used in space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.

Specification

HDMI Resolution:Up to 4K/30Hz

Support Video Format: 8/10/12 bit deep color

Support Audio Format: DTS-HD/ Dolby-true HD/ LPCM7.1/ DTS/ Dolby-AC3/DSD

Max Baud Rate:3×3.4Gbps

Input Cable Distance:4K/30Hz ≤15M AWG26 HDMI standard cable

Output Cable Distance:4K/30Hz ≤15M AWG26 HDMI standard cable

HDMI Input:4 ports

HDMI Output:4 ports

Max Working Current:0.6A

Power Adapter Format:Input: AC (50HZ, 60HZ) 100V-240V;  Output: DC12V/1A

Operating Temperature Range: -15 to +45℃

Operating Humidity Range:5 to 90% RH (No Condensation)

Dimension (L × W × H):276×143×26 (mm)

Weight:720g
