OPT Connector & Adaptor

Features

Cost effective solution for in house termination;

Low insertion loss and added loss;

Height of attenuation;

IP67 to IP68 water, dust proof and corrosion resistant;

RoHS and REACH materials compliant;

The material in the jumpel cable are all-weather and UV-resistant;

Mechanical performance: IEC 61754-20 (DLC), IEC 61754-7 (MPO), IEC 61754-4 (SC);

Type		Reference	Note
LC	IEC 61754-20	Single mode duplex	APC: Green connectors;UPC: Blue connectors
		Multimode duplex	UPC: Grey Connector
MPO	IEC 61754-7	Single mode duplex	APC: Black connectors APC: Black connectors
		Multimode duplex	PC: Black Connectors
MTP	IEC 61754-7	Single mode duplex	APC: Black connectors APC: Black connectors
		Multimode duplex	PC: Black Connectors
SC	IEC 61754-4	Single mode duplex	APC: Green connectors UPC: Blue connectors
		Multimode duplex	UPC: Grey Connectors
